A versatile infrared quartz heating element (250–1,000 W) that delivers an immediate heat response across a wide range of industrial process applications. These elements are especially effective in manufacturing environments where rapid heater reaction times are essential.

• Average weight: 388g
• Size: 123,5 x 123,5 x 22,5 mm
• Useful wavelength range: 1.5 – 8 microns
• Heater Voltage: 230 V standard
• Other Variations: voltages, wattages, lead length and terminations available on request
• Average Operating Life: 10,000 hrs depending on conditions
• Iron-chrome aluminium resistance wire
• Recommended radiation distance from heater is 100 – 200 mm
• Minimum recommended spacing between elements: 5 mm.
• Supplied with 120 mm ceramic beaded power leads
• Ensure temperature of the aluminium clad steel body does not exceed 500 °C (932 °F).
• Element should always be mounted so the quartz glass tubes are horizontal.
